| Model Number : | STL285N4F7AG |
| Certification : | ROHS |
| Price : | Negotiated |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability : | 1000pcs |
| Delivery Time : | 3-15days |
Bom List Mcu Electronic Components STM32F205ZET6 M24512-DFDW6TP STL285N4F7AG STP70N10F4 Ic Chip
Product Attributes
| TYPE | DESCRIPTION |
| Category | Discrete Semiconductor Products |
| Transistors - FETs, MOSFETs - Single | |
| Mfr | STMicroelectronics |
| Series | STripFET™ F7 |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 40 V |
| Current - Continuous Drain (Id) @ 25°C | 120A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 1.1mOhm @ 24A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 67 nC @ 10 V |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 5600 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 188W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PowerFlat™ (5x6) |
| Package / Case | 8-PowerVDFN |
| Base Product Number | STL285 |
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.29.0095 |
Electronic components ICXP various brands of high quality goods Can
be applied to automobile appliance chips of various kinds of
consumer appliances
To better ensure the safety of your goods, professional,
environmentally friendly, convenient and efficient packaging
services will be provided.
FAQ
Q1:What’s your MOQ?
No MOQ needed, And if you buy more, Will enjioy better prices.
Q2:Can I get a Free Sample?
You can ask our staff for apply Free Samples.
Q3:What payment methods do you support?
We provide: Visa / MasterCard / Wire Transfer / WU / MG / PayPal
etc...
Q4:What about the shipment methods?
We provide: DHL / UPS / TNT / FedEx / EMS / Aramex / ePacket etc...
Q5:How will you Guaranteed quality? Quality Warranty Period:12 Months Q6:Are the products tested before shipment?
All products were tested before shipment, and the quality problems
werenegligible.
Q7:Do you provide BOM services?
Yes, We provide one-stop purcharse service, Please send us your BOM
list.
|
|
