| Model Number : | UVZ1H103MRD |
| Certification : | ROHS |
| Price : | Negotiated |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability : | 1000pcs |
| Delivery Time : | 3-15days |
UVZ1H103MRD BOM Service CAP ALUM 10000UF 20% 50V RADIAL UVZ1H103MRD
| TYPE | DESCRIPTION |
| Category | Capacitors |
| Aluminum Electrolytic Capacitors | |
| Mfr | Nichicon |
| Series | UVZ |
| Package | Bulk |
| Product Status | Obsolete |
| Capacitance | 10000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.85 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.2775 A @ 10 kHz |
| Lead Spacing | 0.492" (12.50mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 2.047" (52.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
Documents & Media
| RESOURCE TYPE | LINK |
| Datasheets | UVZ Series |
| Miniature Type Taping Spec | |
| Video File | Doctor Capacitor® Episode Eight: Nichicon Kitchen (or, all about soldering) |
| Doctor Capacitor® Episode Nine: You Callin' Me? | |
| Doctor Capacitor® Episode Seven: What's In The Mail, Doc? | |
| Doctor Capacitor Episode Two: Terms | |
| Doctor Capacitor Episode Three: Failure Modes | |
| Design Resources | 20 W Non-Isolated Buck LED Driver Using PL LNK460KG |
| HTML Datasheet | UVZ Series |
| Miniature Type Taping Spec | |
| EDA Models | UVZ1H103MRD - Models |
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8532.22.0040 |
Additional Resources
| ATTRIBUTE | DESCRIPTION |
| Other Names | 493-1350 |
| Standard Package | 140 |
FAQ
Q1:What’s your MOQ?
No MOQ needed, And if you buy more, Will enjioy better prices.
Q2:Can I get a Free Sample?
You can ask our staff for apply Free Samples.
Q3:What payment methods do you support?
We provide: Visa / MasterCard / Wire Transfer / WU / MG / PayPal
etc...
Q4:What about the shipment methods?
We provide: DHL / UPS / TNT / FedEx / EMS / Aramex / ePacket etc...
Q5:How will you Guaranteed quality? Quality Warranty Period:12
Months Q6:Are the products tested before shipment?
All products were tested before shipment, and the quality problems
werenegligible.
Q7:Do you provide BOM services?
Yes, We provide one-stop purcharse service, Please send us your BOM
list.
|
|
